Explanation of the loom type letters and numbers:
T = loom
E = driven by eccentric curves
M = medium loom construction
2AR = weft insertion by n. 2 rigid rods
3200 = weaving width (on request be possible weaving in 7m width)
TECHNICAL FEATURE OF THE LOOM
- Weaving width: mm 3200 up to 7000m;
- Adjustable speed from 0 up to 250 rpm;
- Maximum beat-up tension: daN/m 3.000;
- Maximum warp tension: daN/m 2.000;
- Modular steel structure with;
- n. 3 complementary driving cams;
- 3-ROLLER TAKE-UP with CONSTANT FABRIC TENSIONING
DEVICE;
- 3-ROLLER WARP TENSIONING DEVICES equipped with its software for the axis control and load cells control (possibility to have a normal let-off beam);
- Warp control tension 4 position;
ELECTRONIC, ROTARY DOBBY TRINCA TYPE R.E.R 12
R = Dobby
E = Electronically controlled
R = Rotary
Suitable for driving from 2 to 52 heddle frames complete with:
- dobby driven and controlled by the PC;
- possibility of weaving with open shed and closed shed;
- possibility to put the heddle frames onto its “0” point;
- possibility to control and adjust manually each single frame;
- possibility to adjust the frame position as needed by each fabric pattern and function of frames in the upper or in the lower part;
- possibility of the frame standstill adjustments;
- possibility of the frame phase adjustment;
- fabric Multipatern.
LOOM CONTROL DEVICE:
The complete loom control, all data settings and operating function adjustments are carried out by the TRINCA electronic control device and the especially developed TRINCA loom managing. All electronically and electric control devices are installed inside the main switchboard and all data’s, as well as loom driving and control functions, are developed by an industrial PC with software windows CE.
